Package contents
Check your motherboard package for the following items.
Motherboard ROG STRIX B350-F GAMING
Cables
4 x SATA 6Gb/s cables
1 x Cable for RGB Header (80cm 1 x 4-pin)
Accessories
1 x I/O Shield
1 x M.2 Screw package
1 x ROG cable label
1 x ROG Coaster
1 x Strix sticker
1 x Cable tie black
Application DVD Support DVD
Documentation User manual
If any of the above items is damaged or missing, contact your retailer.
