Asus ROG STRIX B350-F GAMING [17/78] Recommended memory configurations
![Asus ROG STRIX B350-F GAMING [17/78] Recommended memory configurations](/views2/1233086/page17/bg11.png)
ASUS ROG STRIX B350-F GAMING
1-5
Chapter 1
1.1.4 System memory
ThemotherboardcomeswithfourDDR4(DoubleDataRate4)DualInlineMemory
Modules(DIMM)slots.
Recommended memory congurations
ADDR4moduleisnotcheddifferentlyfromaDDR,DDR2,orDDR3module.DONOT
installaDDR,DDR2,orDDR3memorymoduletotheDDR4slot.
strix b350-F GAMING
ROG STRIX B350-F GAMING
288-pin DDR4 DIMM sockets
DIMM_A1
DIMM_A2
DIMM_B1
DIMM_B2
