xii
Installation tools and components
The tools and components listed above are not included in the motherboard package.
PC chassis
Power supply unit
AMD AM4 compatible CPU Fan
AMD AM4 CPU
DIMM
SATA hard disk drive
Graphics card
Phillips (cross) screwdriver
SATA optical disc drive (optional)
1 bag of screws
