Chapter 1: Product Introduction

Chapter 1

2. RGB headers (4-pin RGB_HEADER1/2)

TheseheadersareforRGBLEDstrips.

TheRGBheadersupports5050RGBmulti-colorLEDstrips(12V/G/R/B),withamaximum

powerratingof2A(12V),andnolongerthan2m.

Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyisswitched

offorthepowercordisdetachedfromthepowersupply.Failuretodosomaycausesevere

damagetothemotherboard,peripherals,orcomponents.

• ActuallightingandcolorwillvarywithLEDstrip.

• IfyourLEDstripdoesnotlightup,checkiftheRGBLEDextensioncableandthe

RGBLEDstripisconnectedinthecorrectorientation,andthe12Vconnectoris

alignedwiththe12Vheaderonthemotherboard.

• TheLEDstripwillonlylightupwhenthesystemisoperating.

• TheLEDstripsarepurchasedseparately.

PIN 1

+12V

RGB_HEADER2

ROG STRIX B350-F GAMING RGB HEADERS

RGB_HEADER1

strix b350-F GAMING
