41
ASUS ROG & ROG STRIX Z200 Series Feature Manual
Record Studio
On my voice switch
You may enable or disable all Perfect Voice effects on your voice by clicking on the
ON or OFF button.
Noise Reduction
Check this box to enable Noise Reduction. This item removes the remaining voice
on top of your voice or your friend’s voice.
Volume Stabilizer
Check this box to enable Volume Stabilizer on your voice or on incoming voice
to maintain constant and clear communication. Use the slider to adjust the MIC
volume.
Acoustic Echo Cancellation
Check this box to enable Acoustic Echo Cancellation. This item removes the echo
which appears in noisy environments.
Voice Equalizer
Check this box to enable the Voice Equalizer. This item allows you to set a 10-band
EQ for your voice when using a microphone.
