ASUS ROG & ROG STRIX Z200 Series Feature Manual
GPU Boost
Click to save the
changes to a profile
Click to load the
saved profile
Click to apply
the changes
Click to undo
the changes
Click to enable the
default settings
CPU Graphics Voltage Adjustments
