xi
TUF X299 MARK 1 specifications summary
(continued on the next page)
LAN
Gigabit Intel LAN connection- 802.3az Energy Efcient Ethernet (EEE)
appliance
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated Media
Access Controller (MAC) and physical layer (PHY)
Intel
®
I211 Gigabit LAN controller
TUF LANGuard
ASUS Turbo LAN Utility
ASUS Features
- USB BIOS Flashback
- TPU
- EPU
- AURA SYNC
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- Turbo LAN to experience smooth online gaming with lower pings and less
lags
- Intel
®
VROC Ready
- AI Suite 3
- ASUS Q-Connector
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS O.C. Prole
- ASUS CrashFree BIOS 3
- EZ Update
- ASUS EZ Flash 3
- Multi-language BIOS
USB
Intel
®
X299 Chipset
- 8 x USB 3.1 Gen 1 ports (4 ports @mid-board, 4 port @back panel, blue)
- 6 x USB 2.0/1.1 ports (2 ports @mid-board, 4 port @back panel, black)
ASMedia
®
USB 3.1 Gen 2 controllers- supports 3A power output
- 1 x USB 3.1 Gen 2 front panel connector*
- 1 x USB 3.1 Gen 2 ports @back panel (teal blue, Type A)
- 1 x USB 3.1 Gen 2 port @back panel (Type C)
