Asus TUF X299 MARK 1 [14/112] Package contents

xiv

Package contents

Check your motherboard package for the following items.

Motherboard ASUS TUF X299 MARK 1 motherboard

Cables 4 x Serial ATA 6.0 Gb/s cables

Accessories

1 x SLI HB BRIDGE(2-WAY-M)

1 x SLI BRIDGE(3-WAY)

1 x Q-Connector

1 x M.2 vertical bracket

1 x M.2 screw package

1 x ASUS Q-Shield

1 x TUF VGA holder

1 x TUF Dongle

1 x TUF INSIDE sticker

1 x STAY COOL BE TUF sticker

1 x TUF accessory package

- 3 x PCIe x16 slot dust covers

- 1 x PCIe x4 slot dust covers

Application DVD Motherboard support DVD

Documentation

1 x User manual

1 x TUF 5 Year Warranty manual (by region)

1 x TUF Certication card

If any of the above items is damaged or missing, contact your retailer.
