xii
TUF X299 MARK 1 specifications summary
(continued on the next page)
Exclusive TUF
Features
“Ultimate COOL!” Thermal Solution
- TUF Thermal Armor
- TUF Thermal Radar 3
- TUF ICe
“We Got Your Back!” Shape Force
- TUF Fortier
- ASUS SafeSlot
- TUF VGA holder
“TUF ENGINE!” Power Design
- 8+2 Digital Phase Power Design
- TUF Components (10K Ti-Cap, TUF Chokes & MOSFET; certied by
military-standard)
“Safe & Stable!” Guardian Angel
- TUF Detective 2
- TUF ESD Guards 2
- Dust Defenders
- MemOK!
Internal I/O
connectors
2 x USB 3.1 Gen 1 connectors support additional 4 USB ports (19-pin)
1 x USB 2.0/1/1 connector supports additional 2 USB ports
1 x M.2_1 Socket 3 (for M Key, type 2242/2260/2280 devices)
1 x Vertical M.2_2 Socket 3 (for M Key, type 2242/2260/2280/22110 devices)
8 x SATA 6.0Gb/s connectors
1 x CPU Fan connector (4-pin) for both 3-pin(DC mode) and 4-pin (PWM
mode) CPU coolers control with auto detection support
1 x CPU OPT Fan connector (4-pin)
1 x W_Pump+ header (4-pin)
5 x Chassis Fan connectors (4-pin) for both 3-pin (DC mode) and 4-pin
(PWM mode) coolers control
1 x H_AMP_FAN (4-pin) for both 3-pin (DC mode) and 4-pin
(PWM mode) control
1 x Assistant Fan connector (4-pin)
1 x Front panel audio connector (AAFP)
1 x Thunderbolt header (5-pin) for ASUS ThunderboltEX series support
1 x TPM connector
1 x 24-pin EATX Power connector
1 x 8-pin EATX 12V Power connector
1 x 4-pin EATX 12V Power connector
1 x System Panel (Q-Connector)
1 x COM port
1 x MemOK! button
1 x Clear CMOS jumper
3 x T_Sensor (Thermal Sensor) headers
