Asus TUF X299 MARK 1 [15/112] Installation tools and components

Installation tools and components

The tools and components in the table above are not included in the motherboard package.

PC chassis

Power supply unit

Intel

LGA 2066 compatible CPU Fan

Intel

LGA 2066 CPU

DIMM

SATA hard disk drive

Graphics card

Phillips (cross) screwdriver

SATA optical disc drive (optional)

M.2 SSD module (optional)

1 bag of screws
