Asus TUF X299 MARK 1 [13/112] Tuf x299 mark 1 specifications summary

xiii

BIOS Features

128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0,

ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11

EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modied log,

F12 PrintScreen and ASUS DRAM SPD (Serial Presence Detect) memory

information

Manageability

WfM 2.0, DMI 3.0, WOL by PME, PXE

Support DVD

contents

Drivers

ASUS Utilities

EZ Update

Anti-virus software (OEM version)

Operating

system support

Windows

10 64-bit

Form factor

ATX Form Factor, 12” x 9.6” (30.5 cm x 24.4 cm)

• Specications are subject to change without notice.

• Visit the ASUS website for the software manual.

TUF X299 MARK 1 specifications summary
