3. Open the printer right side media cover.
4. Open the lower front panel.
5. Open the print head lift lever by turning it toward the back of the printer and up.
6. Install the Ribbon:
Place an empty paper core, diameter larger then 33.8 mm, onto the ribbon rewind
spindle toward the front of the printer.
Place a ribbon on the ribbon supply spindle (refer to figure 3)
Feed the ribbon, ink side down, through the frame and up then attach the ribbon
leading edge (with a tape) to the empty paper core.
Manually rotate the ribbon rewind spindle until it is properly stretched.
Note: Both coated side out and coated side in ribbons may be used with this printer.
7.Loading labels:
Place the labels onto the label spindle (refer to figure 3 ).
Feed the label, printing side up, down through the label guide and adjust the label
guide to fit the width of the label, then buckle it onto the media guide bar.
Feed the label beneath the frame and in between the gap / black mark sensor
assembly then over the platen.
Close the print head lift lever.
Adjust the print head pressure adjustment knobs properly according to the label
width and thickness.
Close lower front panel and printer cover.
Switch on the power. Now, the printer is ready to print.
Figure 3. Loading path for printer media
Power-on Utilities
Make sure the ribbon and label media are installed properly as described above.
1.Gap / Black Sensor Calibration
This utility is used to calibrate the sensitivity of the gap / black mark sensor. The gap /
black mark sensor should be calibrated whenever changing the label media or
executing printer initialization. Please follow the steps below to calibrate the gap /
black mark sensor.
Press the MENU button twice to select Main Menu / 2.Sensor Calib.
Press the EXE/INC button to execute gap sensor calibration utility.
2.Printer Initialization
Printer Initialization will restore printer settings as default.
Please follow the steps below to initialize the printer:
Turn off the printer power.
Press and hold PAUSE and FEED button at the same time while turning on the
printer’s power. Do not release the buttons until the message INITIALIZATING is
displayed on the LCD screen.
Self-test
1. Install the ribbon and the label media as above procedures, and close the print head lift
lever.
2. Switch on the power, press the MENU button five time to select Main Menu / 5.Printer
Test, then press EXE/INC button to execute self-test.
What does Self-test do?
Print out thermal print head check pattern.
Print the printer current settings.
※ For further information on printer operation, please refer to the User’s
Manual in software CD disc.
