Smart-UPS X 2000/2200/3000 Vac XL 120/208/230/240 VA Tower/Rack-Mount 4U 8
Test & Diagnostics
UPS self test x x
UPS alarms test x x
UPS calibration test x x
Logs
Last 10 transfer events (if applicable) x
Last 10 fault events (if applicable) x
About
Model identification x x
Part number x x
Serial number x x
UPS manufacture date x x
Replace battery part number x x
External battery part number x x
Battery install date x x
Replace battery date x x
UPS firmware revision x x
NMC Information - part/serial/version
numbers/manufacture date/MAC address/
firmware revision (if applicable)
x
Main Menu Display Description Standard Option Advanced Option
