Smart-UPS X 2000/2200/3000 Vac XL 120/208/230/240 VA Tower/Rack-Mount 4U 4
Rear panel features continued
Installation
UPS
For UPS installation instructions, refer to the Smart-UPS X 2000-3000 VA Installation Guide that is
supplied with the UPS. The guide is also available on the enclosed User Manual CD and the APC by
Schneider Electric web, site at www.apc.com.
PowerChute network management software
For installation instructions, refer to the PowerChute software CD supplied with the UPS. Installation
instructions are also available on the APC by Schneider Electric web site, www.apc.com.
External battery pack (optional)
For installation instructions, refer to the Smart-UPS X 2000-3000 VA External Battery Pack
Installation Guide that is supplied with the external battery pack. The guide is also available on the
enclosed User Manual CD and the APC by Schneider Electric web, site at www.apc.com.
SmartSlot Use the SmartSlot to install an optional Network Management Card (NMC).
Chassis ground screw The UPS has a ground screw for connecting the ground leads on transient voltage
devices. Prior to connecting a ground lead, disconnect the UPS from AC power.
Utility power cable Use the power cable (supplied), to connect the UPS to utility power.
UPS circuit breaker
reset button
Press this button to reset the UPS circuit breaker after an overload condition has
occurred.
Controllable Outlet
Group 1
Connect critical electronic devices such as a computer, monitor, modem or other data
sensitive devices to these outlets.
Controllable Outlet
Group 2
Connect peripheral electronic devices to these outlets.
Controllable Outlet
Group 3
Connect peripheral electronic devices to these outlets
External battery connector Use the external battery cable to connect the UPS to an XLBP.
XLBPs provide extended runtime during power outages. The UPS can support up to
10 external battery packs.
EPO terminal The Emergency Power Off (EPO) terminal allows the user to connect the UPS to a
central EPO system.
Serial port To use PowerChute software, connect the serial cable (supplied), to the Serial port.
Use only interface kits supplied or approved by APC by Schneider Electric. Any
other serial interface cable will be incompatible with the UPS connector.
USB port
Connect a USB cable from a computer to use power management software.
Note: Serial and USB communication can only be used individually, they
cannot be used at the same time.
