Smart-UPS X 2000/2200/3000 Vac XL 120/208/230/240 VA Tower/Rack-Mount 4U 2
Specifications
For additional specifications, refer to the APC by Schneider Electric web site at www.apc.com.
Temperature
Operating 0° to 40° C (32° to 104° F)
Storage -15° to 45° C (5° to 113° F)
charge UPS battery every six months
Maximum
Elevation
Operating 3,000 m (10,000 ft)
Storage 15,000 m (50,000 ft)
Humidity
0% to 95% relative
humidity,
non-condensing
0° to 40° C (32° to 104° F)
Battery
Maintenance free,
sealed lead acid
Battery cartridge weight: 23.8 kg (52.4 lb)
UPS weight: 17.2 kg (38 lb)
UPS + battery cartridge weight: 41 kg (90.4 lb)
SMX120BP chassis weight: 13.24 kg (29.2 lb)
SMX120BP chassis + battery cartridge weight: 47.54 kg (104.8 lb)
