Smart-UPS X 2000/2200/3000 Vac XL 120/208/230/240 VA Tower/Rack-Mount 4U
5
Operation
Connect Equipment
Note: The UPS will charge to 90% capacity in the first three hours of normal operation. Do not
expect full battery runtime capability during this initial charge period.
1. Connect equipment to the outlets on the rear panel of the UPS.
Refer to “Switched Outlet Groups” on page 12.
2. Connect the UPS to the building utility power. Connect the UPS to a two pole, three wire,
grounded source only.
3. To use the UPS as a
MASTER ON/OFF switch, turn on equipment that is connected to the UPS.
4. To turn on the UPS and all connected equipment. Press the
ON/OFF button on the front panel of the
UPS.
5. Follow the prompts to configure the UPS using the set up wizard the first time the UPS is turned
on. Refer to “Configuration” on page 9 and “Menu overview” on page 6.
Network Management Card settings
These settings are available only on units that have a Network Management Card (NMC).
• NMC IP Address Mode
• NMC Default Gateway
CAUTION
RISK OF EQUIPMENT DAMAGE
• Adhere to all local and national electrical codes.
• Wiring should be performed by qualified electrician.
• Always connect the UPS to a grounded outlet.
Failure to follow these instructions can result in equipment damage
