STRIX H270I GAMING specifications summary
ASUS Special
Features
ASUS EZ DIY
- ASUS EZ Flash 3
- ASUS CrashFree BIOS 3
Gamers Guardian
- SafeSlot
- DRAM Overcurrent Protection
- ESD Guards on LAN, Audio, KBMS, and USB3.0/2.0 ports
- Highly Durable Components
Rear Panel I/O
Ports
1 x HDMI 1.4b
1 x DisplayPort 1.2
6 x USB 3.0 ports [blue]
2 x Anti-surge LAN (RJ45) ports
1 x ASUS Wi-Fi Module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth v4.1)
1 x Optical S/PDIF out
5 x Audio jacks
Internal I/O
connectors
1 x USB 3.0 header supports additional 2 USB 3.0 ports
4 x SATA 6Gb/s connectors
1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support
(supports both SATA & PCIe 3.0 modes)
1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support
(supports PCIe 3.0 mode)
1 x 4-pin CPU fan connector
1 x 4-pin chassis fan connector
1 x 4-pin AIO_PUMP connector
1 x Aura RGB header
1 x Clear CMOS/RTC (2-pin)
1 x Front panel audio connector(s) (AAFP)
1 x 8-pin ATX 12V Power connector(s)
1 x 24-pin EATX Power connector(s)
1 x 14-1 pin TPM connector
1 x Internal speaker connector
1 x System panel(s)
BIOS Features
1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, SM BIOS 3.0, ACPI
5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ
Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modied log, F12
PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence
Detect) memory information.
Manageability
DMI3.0, WOL by PME, PXE
(continued on the next page)
