3-12

Chapter 3: BIOS Setup

Chapter 3

Intel(R) SpeedStep(tm) [Auto]

This item allows the operating system to dynamically adjust the processor voltage and cores

frequency, resulting to a decreased average power consumption and decreased average

heat production. Conguration options: [Auto] [Disabled] [Enabled]

Turbo Mode Parameters

Long Duration Package Power Limit [Auto]

Allows you to limit the Turbo Ratio’s time duration that exceeds the TDP (Thermal

Design Power) for maximum performance. Use the <+> or <-> keys to adjust the value.

The values range from 1 W to 4095 W.

Package Power Time Window [Auto]

Also known as Power Limit 1, this item allows you to maintain the time window for

Turbo Ratio over TDP (Thermal Design Power). Use the <+> or <-> keys to adjust the

value. The values range from 1 to 127 in seconds.

Short Duration Package Power Limit [Auto]

Also known as Power Limit 2, this item allows you to provide rapid protection when

the package power exceeds the Power Limit 1. Use the <+> or <-> keys to adjust the

value. The values range from 1 W to 4095 W.

IA AC Load Line [Auto]

This item allows you to set the AC loadline dened in 1/100 mOhms. Use the <+> and <->

keys to adjust the value. Conguration options: [Auto] [0.01] - [62.49]

IA DC Load Line [Auto]

This item allows you to set the DC loadline dened in 1/100 mOhms. Use the <+> and <->

keys to adjust the value. Conguration options: [Auto] [0.01] - [62.49]

3.6 Advanced menu

The Advanced menu items allow you to change the settings for the CPU and other system

devices.

Be cautious when changing the settings of the Advanced menu items. Incorrect eld values

can cause the system to malfunction.

3.6.1 Platform Misc Configuration

The items in this menu allow you to congure the platform-related features.

3.6.2 CPU Configuration

The items in this menu show the CPU-related information that the BIOS automatically

detects.

The items shown in submenu may be different due to the CPU you installed.
