Chapter 1: Product Introduction
Chapter 1
Layout contents
Connectors/Jumpers/Buttons and switches/Slots Page
1. ATXpowerconnectors(24-pinEATXPWR,8-pinEATX12V) 1-12
2. M.2sockets(M.2_1~2) 1-15
3. LGA1151CPUsocket 1-4
4. CPU,AIOpump,andchassisfanconnectors
(4-pinCPU_FAN,4-pinAIO_PUMP,4-pinCHA_FAN)
1-14
5. DDR4DIMMslots 1-5
6. POSTStateLEDs 1-10
7. RGBLEDStandbypowerLED(SB_PWR) 1-10
8. RGBheader(4-pinRGB_HEADER) 1-9
9. Systempanelconnector(10-1pinPANEL) 1-16
10. Speakerconnector(4-pinSPEAKER) 1-11
11. Intel
®
SerialATA6Gb/sconnectors(7-pinSATA6G_1~4) 1-13
12. USB3.0connectors(20-1pinUSB3_12) 1-11
13. ClearRTCRAMjumper(2-pinCLRTC) 1-8
14. TPMconnector(14-1pinTPM) 1-13
15. Frontpanelaudioconnector(10-1pinAAFP) 1-12
16. RTCBatteryheader(2-pinBATT_CON) 1-8
1.1.3 Central Processing Unit (CPU)
ThemotherboardcomeswithasurfacemountLGA1151socketdesignedforthe7th/6th
GenerationIntel
®
Core™i7/Intel
®
Core™i5/Intel
®
Core™i3,Pentium
®
,andCeleron
®
processors.
STRIX H270I GAMING CPU socket LGA1151
