1-2
Chapter 1: Product Introduction
Chapter 1
• Referto1.1.8 Internal connectors and 2.2.1 Rear I/O connection for more
information about rear panel connectors and internal connectors.
• M2_2 is located on the bottom of the motherboard.
1.1.2 Motherboard layout
17.0cm(6.7in)
17.0cm(6.7in)
EATXPWR
RGB_HEADER
DDR4 DIMM_A1 (64bit, 288-pin module)
M.2_1(SOCKET3)
M.2_2(SOCKET3)Bottom
DDR4 DIMM_B1 (64bit, 288-pin module)
CPU_LED
DRAM_LED
VGA_LED
BOOT_DEVICE_LED
F_PANEL
SATA6G_1
SATA6G_2
SATA6G_3SATA6G_4
SPEAKER
HDMI DP
BATT_CON
USB3_12
PCIEX16
TPM
2280
2260
CHA_FAN
AIO_PUMPCPU_FAN
EATX12V
Intel
®
H270
PCIE SATA IRST
X4 VV
Intel
®
I219V
LGA1151
AAFP
LAN1_USB3_34
LAN2_USB3_78
USB3_56
M.2(WIFI)
AUDIO
Super
I/O
CLRTC
DIGI
+VRM
(Bottom)
128Mb
BIOS
RGBLED
SupremeFX
S1220A Codec
Realtek
®
RTL8111H
(Bottom)
1
7
1
8
9
10
11
12
414
11
13
15
16
54 632
