viii
STRIX H270I GAMING specifications summary
CPU
Intel
®
socket 1151 for 7th/ 6th Generation Core™ i7/ Core™ i5/ Core™ i3/
Pentium
®
, and Celeron
®
processors*
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0**
* Refer to www.asus.com for Intel
®
CPU support list.
** The Intel
®
Turbo Boost Technology 2.0 support depends on the CPU types.
Chipset
Intel
®
H270 Chipset
Memory
2 x DIMM, max. 32GB DDR4 2400* /2133** MHz Non-ECC, Un-buffered Memory
Dual channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)***
* Due to Intel
®
chipset limitation, DDR4 2400MHz memory frequency is only supported
by 7th Generation Intel
®
processors. Higher memory modules will run at the maximum
transfer rate of DDR4 2400MHz.
** Due to Intel
®
chipset limitation, DDR4 2133MHz and higher memory modules on 6th
Generation Intel
®
processors will run at the maximum transfer rate of DDR4 2133MHz.
*** Refer to www.asus.com for the lastest Memory QVL(Qualified Vendors List).
Expansion slots
1 x PCIe 3.0 x16 slot
VGA
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support: HDMI/ DisplayPort ports
Supports HDMI 1.4b with max. resolution 4096 x 2160@24Hz
Supports DisplayPort 1.2 with max. resolution 4096 x 2304 @60Hz
Supports Intel
®
InTru™ 3D/Quick Sync Video/Clear Video HD Technology/
Insider™
Maximum shared memory of 1024 MB
Storage
Intel
®
H270 Chipset with RAID 0, 1, 5, 10 and Intel
®
Rapid Storage
Technology 15 support
- 4 x SATA 6Gb/s ports
- 1 x M.2_1 Socket 3 with M Key, type 2242/2260/2280 (supports both PCIe 3.0
x4 and SATA modes)*
- 1 x M.2_2 Socket 3 with M Key, type 2242/2260/2280 (supports PCIe 3.0 x4
mode)*
- Intel
®
Optane
TM
Memory Ready**
- Supports Intel
®
Smart Response Technology***
* For a 2242 storage device, use the bundled 2242 mounting kit.
**
Intel
®
Optane
TM
Technology is only supported when using 7th Generation Intel®
Processors. Before using Intel
®
Optane
TM
memory modules, ensure that you have
updated your motherboard drivers and BIOS to the latest version from ASUS support
website.
*** This function will work depending on the CPU installed.
LAN
Intel
®
I219-V Gigabit LAN- Dual interconnect between the integrated Media
Access Controller (MAC) and physical layer (PHY)
Realtek
®
RTL8111H Gigabit LAN
Anti-surge LANGuard
ROG GameFirst IV*
* ROG GameFirst Technology is only available for Windows 10/8.1 64-bit.
(continued on the next page)
