![Asus ROG STRIX B250G GAMING [10/72] Strix b250g gaming specifications summary](/img/pdf.png)
Asus ROG STRIX B250G GAMING [10/72] Strix b250g gaming specifications summary
![Asus ROG STRIX B250G GAMING [10/72] Strix b250g gaming specifications summary](/views2/1254549/page10/bga.png)
x
STRIX B250G GAMING specications summary
Internal I/O
connectors
2 x USB 3.0 connectors support additional 4 USB 3.0 ports
1 x USB 2.0 connector supports additional 2 USB 2.0 ports
6 x SATA 6Gb/s connectors
1 x COM connector
1 x 4-pin CPU fan connector
1 x 4-pin chassis fan connector
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x M.2_1 Socket 3 for M Key, type 2242/2260/2280 storage devices support
(Supports PCIe 3.0 x4 and SATA modes)
1 x M.2_2 Socket 3 for M Key, type 2242/2260/2280/22110 storage devices
support (Supports PCIe 3.0 x4 mode only)
1 x Front panel audio connector (AAFP)
1 x TPM connector
1 x System panel connector
1 x Clear CMOS jumper (2-pin)
BIOS Features
128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0,
ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6
Qfan Control, F3 My Favorites, Last Modied log, F12 PrintScreen, and ASUS
DRAM SPD (Serial Presence Detect) memory information
Manageability WfM2.0, DMI3.0, WOL by PME, PXE
Support DVD
contents
Drivers
ASUS Utilities
EZ Update
Anti-virus software (OEM version)
Operating
system support
Windows
®
10 64-bit
Windows
®
8.1 64-bit*
Windows
®
7*
* Windows
®
8.1 64-bit and Windows
®
7 32/64-bit are only supported when using 6th
Generation Intel
®
Processors.
Form factor mATX Form Factor, 9.6” x 8.6” (24.4cm x 21.8cm)
• Specications are subject to change without notice.
• Visit the ASUS website for the software manual.
