1-6
Chapter 1: Product Introduction
Chapter 1
1.1.5 Expansion slots
Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay
cause you physical injury and damage motherboard components.
Slot No. Slot Description
1 PCIex16_1slot
2 PCIex1_1slot
3 PCIex1_2slot
PCIEX16_1
PCIEX1_2
PCIEX1_1
