ASUS STRIX B250G GAMING

1-3

Chapter 1

Layout contents

Connectors/Jumpers/Buttons and switches/Slots Page

1. ATXpowerconnectors(24-pinEATXPWR,8-pinEATX12V) 1-12

2. CPUandchassisfanconnectors(4-pinCPU_FAN,4-pinCHA_FAN) 1-11

3. M.2sockets(M.2_1~2) 1-14

4. LGA1151CPUsocket 1-3

5. DDR4DIMMslots 1-4

6. Intel

SerialATA6Gb/sconnectors(7-pinSATA6G_1~6) 1-12

7. StandbypowerLED(SB_PWR) 1-8

8. Systempanelconnector(20-5pinPANEL) 1-13

9. ClearRTCRAMjumper(2-pinCLRTC) 1-7

10. USB3.0connectors(20-1pinUSB3_12,USB3_34) 1-10

11. USB2.0connector(10-1pinUSB1112) 1-10

12. TPMconnector(14-1pinTPM) 1-11

13. Serialportconnector(10-1pinCOM) 1-9

14. Frontpanelaudioconnector(10-1pinAAFP) 1-9

15. SupremeFXLED 1-8

1.1.3 Central Processing Unit (CPU)

ThemotherboardcomeswithasurfacemountLGA1151socketdesignedforthe7th/6th

GenerationIntel

Core™i7/Intel

Core™i5/Intel

Core™i3,Pentium

,andCeleron

processors.

• EnsurethatallpowercablesareunpluggedbeforeinstallingtheCPU.

• Uponpurchaseofthemotherboard,ensurethatthePnPcapisonthesocketand

thesocketcontactsarenotbent.ContactyourretailerimmediatelyifthePnPcap

ismissing,orifyouseeanydamagetothePnPcap/socketcontacts/motherboard

components.

• Keepthecapafterinstallingthemotherboard.ASUSwillprocessReturnMerchandise

Authorization(RMA)requestsonlyifthemotherboardcomeswiththecaponthe

LGA1151socket.

• Theproductwarrantydoesnotcoverdamagetothesocketcontactsresultingfrom

incorrectCPUinstallation/removal,ormisplacement/loss/incorrectremovalofthePnP

cap.

STRIX B250G GAMING CPU socket LGA1151
