STRIX B250G GAMING specications summary
Audio
SupremeFX S1220A 8-Channel High Denition Audio CODEC
- Supports up to 32-Bit/192kHz playback*
- Impedance sense for front and rear headphone outputs
- High quality 120dB SNR stereo playback output and 113dB SNR recording
input
- SupremeFX Shielding Technology
- Dual Headpone Ampliers
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-channel audio and due to Windows
®
7 limitations, 32-bit playback is
unavailable for Windows
®
7.
ROG Exclusive
Features
ROG Overwolf
ROG CPU-Z
ASUS Special
Features
Performance Optimization
- GPU Boost
- Fan Xpert 3
- AI Suite 3
Gamers Guardian
- SafeSlot
- DIGI+ VRM
- DRAM Overcurrent Protection
- ESD Guards on LAN, Audio, KBMS, and USB3.0/2.0 ports
- Highly Durable Components
- Stainless Steel Back I/O
ASUS EZ DIY
- ASUS EZ Flash 3
- ASUS CrashFree BIOS 3
ASUS Q-Design
- Q-Shield
- Q-Slot
- Q-DIMM
ASUS Exclusive Features
- Ai Charger
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
Rear Panel I/O
Ports
1 x PS/2 keyboard/mouse combo port
1 x DVI-D port
1 x HDMI port
4 x USB 2.0 ports
2 x USB 3.0 ports [blue]
1 x Anti-surge LAN (RJ45) port
3 x Audio jacks*
* Use a chassis with HD audio module in the front panel to support an 8-channel
audio output.
