Asus ROG STRIX B250G GAMING [20/72] Chapter 1

1-8

Chapter 1: Product Introduction

Chapter 1

1.1.7 Onboard LEDs

1. Standby Power LED (SB_PWR)

ThemotherboardcomeswithastandbypowerLED.TheLEDlightsuptoindicatethat

thesystemisON,insleepmode,orinsoft-offmode.Thisisareminderthatyoushould

shutdownthesystemandunplugthepowercablebeforeremovingorplugginginany

motherboardcomponent.TheillustrationbelowshowsthelocationoftheonboardLED.

STRIX B250G GAMING Onboard LED

SB_PWR

Standby Power

Powered Off

OFF

2. SupremeFX LED

TheSupremeFXLEDlightsupinthefollowingtwowaystobringyouanultimate

lightingeffect.ThisLEDalsooutlinestheseparationoftheaudiocomponentsfromthe

rest of your motherboard.

Lit mode Description

Breathingmode TheLEDblinksintermittently.

Still mode TheLEDbecomessolidred.

YoucanturnofftheSupremeFXLEDorchangethelitmodesfromtheBIOSortheLED

ControlappinAiSuite3.TochangethesettinginBIOS,gotoAdvanced > Onboard

Devices Conguration > SupremeFX LED Lighting item. See section 3.6.7 Onboard

Devices Conguration for details.

STRIX B250G GAMING SupremeFX LED Lighting

SupremeFX LED
