Adaptec ASR-8405 SGL — настройки BIOS контроллера: управление загрузкой и производительностью [92/117]

Содержание

• Raid_iug pdf p.1
• Revision history p.3
• Contents p.4
• Adaptec by pmc product support p.8
• Limited 3 year hardware warranty p.10
• Regulatory compliance statements p.11
• This equipment is home use class b electromagnetic wave suitability equipment and to be used mainly at home and it can be used in all areas p.13
• Asr 81605zq afm 700 p.13
• Terminology used in this guide p.14
• About this guide p.14
• What you need to know before you begin p.14
• How to find more information p.15
• System requirements p.16
• Kit contents p.16
• Kit contents and system requirements p.16
• Standard raid controller features p.17
• About your raid controller p.17
• Array level features p.17
• Advanced data protection suite p.17
• Upgrading the controller firmware p.18
• Adding a flash backup module p.18
• Activity leds p.19
• Diagnostic leds p.19
• Aggregate activity p.19
• Pcie x8 connector p.19
• Hda mode connector p.19
• Daughterboard connector p.19
• Back of card p.19
• About the adaptec raid 6405 p.19
• The adaptec raid 6405 is a sas raid controller with these features p.19
• Mounting bracket p.19
• Internal mini sas connector cn0 p.19
• I2c connector for cn0 p.19
• Ext alarm connector p.19
• Drive activity led connector f or cn0 p.19
• The adaptec raid 6445 is a sas raid controller with these features p.20
• About the adaptec raid 6445 p.20
• About the adaptec raid 6805 6805q p.21
• The adaptec raid 6805 6805q is a sas raid controller with these features p.21
• Ext alarmconnector aggregate activity p.22
• Drive activity led connector for cn0 p.22
• About the adaptec raid 6405e p.22
• The adaptec raid 6405e is a sas raid controller with these features p.22
• Pcie x1 connector p.22
• Mounting bracket p.22
• Internal mini sas connector cn0 p.22
• Hda mode connector p.22
• The adaptec raid 6805e 6805e r5 is a sas raid controller with these features p.23
• About the adaptec raid 6805e 6805e r5 p.23
• The adaptec raid 6405t is a sas raid controller with these features p.24
• About the adaptec raid 6405t p.24
• The adaptec raid 6805t 6805tq is a sas raid controller with these features p.25
• About the adaptec raid 6805t 6805tq p.25
• Ext alarm connector p.26
• Internal mini sas hd connectors p.26
• Hda mode connector p.26
• Daughterboard connector p.26
• About the adaptec raid 7805 7805q p.26
• The adaptec raid 7805 7805q is a sas raid controller with these features p.26
• Pcie x8 connector p.26
• Mounting bracket p.26
• The adaptec raid 71605 71605q is a sas raid controller with these features p.27
• Pcie x8 connector p.27
• Mounting bracket p.27
• Internal mini sas hd connectors p.27
• Hda mode connector p.27
• Ext alarm connector p.27
• Daughterboard connector p.27
• About the adaptec raid 71605 71605q p.27
• Mounting bracket p.28
• Internal mini sas hd connectors p.28
• Hda mode connector p.28
• Ext alarm connector p.28
• About the adaptec raid 71605e p.28
• The adaptec raid 71605e is a sas raid controller with these features p.28
• Pcie x8 connector p.28
• The adaptec raid 71685 is a sas raid controller with these features p.29
• Pcie x8 connector p.29
• Mounting bracket p.29
• Mini sas hd x4 sff 8644 connectors external p.29
• Internal mini sas hd connectors p.29
• Hda mode connector p.29
• External mini sas hd connectors p.29
• Ext alarm connector p.29
• Daughterboard connector p.29
• About the adaptec raid 71685 p.29
• Hd connectors p.30
• Ext alarm connector p.30
• Daughterboard connector p.30
• About the adaptec raid 72405 p.30
• The adaptec raid 72405 is a sas raid controller with these features p.30
• Pcie x8 connector p.30
• Mounting bracket p.30
• Internal mini sas p.30
• Hda mode connector p.30
• The adaptec raid 78165 is a sas raid controller with these features p.31
• Mini sas hd x4 sff 8644 connectors external p.31
• About the adaptec raid 78165 p.31
• About the adaptec raid 8405 p.32
• The adaptec raid 8405 is a sas raid controller with these features p.32
• The adaptec raid 8805 is a sas raid controller with these features p.33
• About the adaptec raid 8805 p.33
• The adaptec raid 8885 8885q is a sas raid controller with these features p.34
• Mini sas hd x4 sff 8644 connectors external p.34
• About the adaptec raid 8885 8885q p.34
• About the adaptec raid 81605zq p.35
• The adaptec raid 81605zq is a sas raid controller with these features p.35
• Selecting disk drives and cables p.36
• Getting started p.36
• Disk drives p.36
• Choosing a raid level p.36
• Cables p.36
• Replacing the full height bracket with a low profile bracket p.38
• Installation options p.39
• Basic installation steps p.39
• Installing with an operating system p.40
• Installing on an existing operating system p.40
• Installing the controller and disk drives p.41
• Installing the controller p.41
• Installing a raid controller without zero maintenance cache protection p.41
• Before you begin p.41
• Installing a raid controller with zero maintenance cache protection p.42
• Connecting drives to a system backplane p.45
• Connecting drives directly to the controller p.45
• Connecting disk drives to your controllers p.45
• Connecting solid state drives ssds p.46
• Next steps p.47
• Connecting external devices p.47
• Setting the boot controller p.48
• Creating an array with the arc utility p.48
• Creating an array p.48
• Creating a bootable array p.48
• Creating an array with maxview storage manager p.49
• Making your array bootable p.51
• Installing the driver and an operating system p.52
• Creating a driver disk p.52
• Before you begin p.52
• Installing with windows p.53
• Installing with red hat linux 5 or cent os 5 p.53
• Red hat linux 6 cent os 6 with dynamic kernel module support p.53
• Installing with red hat linux 6 cent os 6 or fedora linux p.53
• Red hat linux 6 cent os 6 fedora linux without dynamic kernel module support p.54
• Installing with suse linux enterprise server p.55
• Installing with debian linux p.55
• Installing with ubuntu linux p.56
• Installing with solaris p.57
• Installing with vmware esx 4 p.58
• Installing with freebsd p.58
• Installing with vmware esxi 5 x p.59
• Vmware esxi 5 p.61
• J export the custom iso image vmware esxi 5 p.61
• I add the scsi aacraid software package to the new image profile vmware esxi 5 p.61
• H check if the new driver package is available p.61
• G change the vendor and acceptance level of the new image profile vmware esxi 5 p.61
• You should see a line like this p.61
• Installing with citrix xenserver p.62
• Installing the driver on an existing operating system p.63
• Installing on windows p.63
• Creating a driver disk p.63
• Before you begin p.63
• Installing on red hat cent os suse or fedora linux p.64
• Installing on ubuntu linux p.64
• Installing on debian linux p.64
• Installing on solaris p.65
• Installing on vmware p.66
• Installing on freebsd p.66
• Installing on citrix xenserver p.67
• About maxview storage manager p.68
• About the adaptec raid controller configuration utility p.68
• About the adaptec raid configuration utility p.68
• Managing your storage space p.68
• Installing maxview storage manager p.68
• Which utility should i use p.69
• About the adaptec flash utility p.69
• Troubleshooting checklist p.70
• Solving problems p.70
• Silencing the alarm p.70
• Recovering from a disk drive failure p.70
• Monitoring disk drives status p.70
• Failed disk drive not protected by a hot spare p.71
• Multiple failures in the same array p.71
• Failure in multiple arrays simultaneously p.71
• Failed disk drive protected by a hot spare p.71
• Disk drive failure in a raid 0 array p.71
• Resetting the controller p.72
• Failed ssd in maxcache container p.72
• What is sas p.73
• Terminology used in this appendix p.73
• How do sas devices communicate p.73
• A introduction to sas p.73
• What s a sas port p.74
• What s a sas address p.74
• What s a phy p.74
• What s a sas connector p.75
• What do sas cables look like p.75
• What are the sas connection options p.75
• How are disk drives identified in sas p.75
• Direct attach connections p.75
• Sas expander connections p.76
• Backplane connections p.76
• In summary although sas and parallel scsi both use the scsi command set how they move data from one place to another is very different to support point to point serial data transport sas introduces new types of connectors cables connection options and terminology generally speaking sas is faster and more flexible than parallel scsi and provides more options for building your storage space sas lets you mix sas and sata disk drives together and lets you connect many many more devices this table describes many of the main differences between the two interfaces p.77
• How is sas different from parallel scsi p.77
• When you create arrays or logical drives you can assign a raid level to protect your data each raid level offers a unique combination of performance and redundancy raid levels also vary by the number of disk drives they support this appendix describes the raid levels supported by your adaptec raid controller and provides a basic overview of each to help you select the best level of protection for your data storage p.78
• Understanding drive segments p.78
• Non redundant arrays raid 0 p.78
• B understanding raid p.78
• An array with raid 0 includes two or more disk drives and provides data striping where data is distributed evenly across the disk drives in equal sized sections however raid 0 arrays do not maintain redundant data so they offer no data protection compared to an equal sized group of independent disks a raid 0 array provides improved i o performance drive segment size is limited to the size of the smallest disk drive in the array for instance an array with two 250 gb disk drives and two 400 gb disk drives can create a raid 0 drive segment of 250 gb for a total of 1000 gb for the volume as shown in this figure p.78
• A drive segment is a disk drive or portion of a disk drive that is used to create an array a disk drive can include both raid segments segments that are part of an array and available segments each segment can be part of only one logical device at a time if a disk drive is not part of any logical device the entire disk is an available segment p.78
• Raid 1 arrays p.79
• Raid 1 enhanced arrays p.79
• Raid 10 arrays p.80
• A raid 10 array is built from two or more equal sized raid 1 arrays data in a raid 10 array is both striped and mirrored mirroring provides data protection and striping improves performance drive segment size is limited to the size of the smallest disk drive in the array for instance an array with two 250 gb disk drives and two 400 gb disk drives can create two mirrored drive segments of 250 gb for a total of 500 gb for the array as shown in this figure p.80
• Raid 5 arrays p.81
• A raid 5 array is built from a minimum of three disk drives and uses data striping and parity data to provide redundancy parity data provides data protection and striping improves performance parity data is an error correcting redundancy that s used to re create data if a disk drive fails in raid 5 arrays parity data represented by ps in the next figure is striped evenly across the disk drives with the stored data drive segment size is limited to the size of the smallest disk drive in the array for instance an array with two 250 gb disk drives and two 400 gb disk drives can contain 750 gb of stored data and 250 gb of parity data as shown in this figure p.81
• Raid 5ee arrays p.82
• A raid 5ee array also known as a hot space is similar to a raid 5 array except that it includes a distributed spare drive and must be built from a minimum of four disk drives unlike a hot spare a distributed spare is striped evenly across the disk drives with the stored data and parity data and can t be shared with other logical disk drives a distributed spare improves the speed at which the array is rebuilt following a disk drive failure a raid 5ee array protects your data and increases read and write speeds however capacity is reduced by two disk drives worth of space which is for parity data and spare data in this figure s represents the distributed spare p represents the distributed parity data p.82
• Raid 50 arrays p.83
• A raid 50 array is built from six to forty eight disk drives configured as two or more raid 5 arrays and stripes stored data and parity data across all disk drives in both raid 5 arrays for more information see raid 5 arrays on page 81 the parity data provides data protection and striping improves performance raid 50 arrays also provide high data transfer speeds drive segment size is limited to the size of the smallest disk drive in the array for example three 250 gb disk drives and three 400 gb disk drives comprise two equal sized raid 5 arrays with 500 gb of stored data and 250 gb of parity data the raid 50 array can therefore contain 1000 gb 2 x 500 gb of stored data and 500 gb of parity data in this figure p represents the distributed parity data p.83
• Use this table to select the raid levels that are most appropriate for the logical drives on your storage space based on the number of available disk drives and your requirements for performance and reliability p.84
• Similar to a raid 50 array see raid 50 arrays on page 83 a raid 60 array also known as dual drive failure protection is built from eight disk drives configured as two or more raid 6 arrays and stripes stored data and two sets of parity data across all disk drives in both raid 6 arrays two sets of parity data provide enhanced data protection and striping improves performance raid 60 arrays also provide high data transfer speeds p.84
• Raid 60 arrays p.84
• Raid 6 arrays p.84
• Comparing raid levels p.84
• A raid 6 array also known as dual drive failure protection is similar to a raid 5 array because it uses data striping and parity data to provide redundancy however raid 6 arrays include two independent sets of parity data instead of one both sets of parity data are striped separately across all disk drives in the array raid 6 arrays provide extra protection for your data because they can recover from two simultaneous disk drive failures however the extra parity calculation slows performance compared to raid 5 arrays raid 6 arrays must be built from at least four disk drives maximum stripe size depends on the number of disk drives in the array p.84
• Disk drive usage read performance and write performance depend on the number of drives in the logical drive in general the more drives the better the performance p.85
• Running the arc utility p.86
• Introduction to the arc utility p.86
• Ctrl a or uefi hii p.86
• C using the adaptec raid configuration utility p.86
• Managing existing arrays p.87
• Using the arc utility to create and manage arrays p.87
• Creating bootable arrays p.87
• Creating a new array p.87
• Modifying cache settings p.88
• Modifying power management settings p.88
• Uninitializing disk drives p.89
• Stopping a secure erase p.89
• Secure erasing disk drives p.89
• Rescanning disk drives p.89
• Initializing disk drives p.89
• Managing the maxcache pool p.90
• Managing global hot spares p.90
• Managing existing jbods p.90
• Creating and managing jbods p.90
• Creating a new jbod p.90
• Converting a jbod into a simple volume p.90
• Opening the controller settings tool p.91
• Modifying your controller s configuration p.91
• General controller settings p.91
• Applying changes and exiting p.91
• Using the arc utility to modify controller settings p.91
• Sgpio backplane is connected if any connected sgpio backplane does not support the backplane_type signal or it does not support the ibpi protocol you can manually set the backplane mode to sgpio p.92
• Note with the default ibpi setting the firmware sends a sgpio backplane_type signal if it recognizes that a p.92
• Note when the alarm is turned off disabled it will remain off after a reboot p.92
• Power management settings p.93
• Preserving the controller cache p.94
• Enabling and disabling controller cache preservation p.94
• Clearing the controller cache p.94
• Locating disk drives p.95
• Identifying disk drives p.95
• Formatting and verifying disk drives p.95
• Checking the cache preservation status p.95
• Checking backup unit status p.95
• Updating the controller firmware p.96
• Setting the drive write cache policy p.96
• Viewing the event log p.97
• Creating a support archive p.97
• Updating the controller cpld p.97
• System requirements p.98
• Running the menu based afu p.98
• Obtaining the firmware p.98
• D using the adaptec flash utility p.98
• Creating the firmware update disk p.98
• Compatibility notes p.98
• Before you begin p.98
• Running the afu from the command line p.99
• Afu commands p.99
• Update p.100
• Compares the contents of each of the flash components on a raid controller to the corresponding image in a ufi file and indicates whether they match after using the verify command you must restart the computer the command syntax for th p.101
• Command restart your computer the command syntax for th p.101
• Command is as follows p.101
• Command is p.101
• Version p.101
• Verify p.101
• This example shows a typical system response after a verify command p.101
• This example displays version information about all supported raid controllers p.101
• Functions and command switches p.101
• For example p.101
• Displays version information about the flash components on a raid controller after using th p.101
• Displays a summary o p.101
• Updating the flash using the afu command line p.102
• This appendix provides a reference guide for adaptec raid controller activity led connectors i2c connectors and external alarm connectors p.103
• E controller led i2c and alarm connector quick reference p.103
• Adaptec raid 6405 6445 led and i2c connector specification p.103
• Adaptec raid 6405 6445 i2c cn0 board connector molex 22 43 6030 or equivalent i2c mating cable connector molex 22 43 3030 or equivalent j4 p.103
• Adaptec raid 6405 6445 external alarm connector molex 22 28 4023 or equivalent alarm mating cable connector molex 50 57 9002 or equivalent j12 p.103
• Adaptec raid 6405 6445 aggregate activity led board connector molex 22 28 4023 or equivalent aggregate led mating cable connector molex 50 57 9002 or equivalent j1 p.103
• Adaptec raid 6405 6445 activity led header connector molex 22 43 6030 or equivalent activity led header mating cable connector molex 22 55 2161 or equivalent j2 p.103
• Adaptec raid 6805 6805q led and i2c connector specification p.104
• Adaptec raid 6805 6805q external alarm connector molex 22 28 4023 or equivalent alarm mating cable connector molex 50 57 9002 or equivalent j12 p.104
• Adaptec raid 6805 6805q aggregate activity led board connector molex 22 28 4023 or equivalent aggregate led mating cable connector molex 50 57 9002 or equivalent j1 p.104
• Adaptec raid 6805 6805q activity led header connector molex 22 43 6030 or equivalent activity led header mating cable connector molex 22 55 2161 or equivalent j2 p.104
• Adaptec raid 6805 6805q i2c cn1 board connector molex 22 43 6030 or equivalent i2c mating cable connector molex 22 43 3030 or equivalent j5 p.105
• Adaptec raid 6805 6805q i2c cn0 board connector molex 22 43 6030 or equivalent i2c mating cable connector molex 22 43 3030 or equivalent j4 p.105
• Adaptec raid 6405e led connector specification p.105
• Adaptec raid 6405e aggregate activity led board connector molex 22 28 4023 or equivalent aggregate led mating cable connector molex 50 57 9002 or equivalent j1 p.105
• Adaptec raid 6405e activity led header connector molex 22 43 6030 or equivalent activity led header mating cable connector molex 22 55 2161 or equivalent j2 p.105
• Asr 6805e r5 bulk 2275600 r p.106
• Adaptec raid 6805e 6805e r5 led connector specification p.106
• Adaptec raid 6805e 6805e r5 aggregate activity led board connector molex 22 28 4023 or equivalent aggregate led mating cable connector molex 50 57 9002 or equivalent j1 p.106
• Adaptec raid 6805e 6805e r5 activity led header connector molex 22 43 6030 or equivalent activity led header mating cable connector molex 22 55 2161 or equivalent j2 p.106
• Adaptec raid 6405e external alarm connector molex 22 28 4023 or equivalent alarm mating cable connector molex 50 57 9002 or equivalent j12 p.106
• Adaptec raid 6405t aggregate activity led board connector molex 22 28 4023 or equivalent aggregate led mating cable connector molex 50 57 9002 or equivalent j1 p.107
• Adaptec raid 6405t activity led header connector molex 22 43 6030 or equivalent activity led header mating cable connector molex 22 55 2161 or equivalent j2 p.107
• Adaptec raid 6805t 6805tq led connector specification p.107
• Adaptec raid 6805e 6805e r5 external alarm connector molex 22 28 4023 or equivalent alarm mating cable connector molex 50 57 9002 or equivalent j12 p.107
• Adaptec raid 6405t led connector specification p.107
• Adaptec raid 6405t external alarm connector molex 22 28 4023 or equivalent alarm mating cable connector molex 50 57 9002 or equivalent j12 p.107
• Adaptecraid6805t 6805tqaggregateactivityledboardconnector molex22 28 4023orequivalent aggregate led mating cable connector molex 50 57 9002 or equivalent j1 p.108
• Adaptec raid 7805 7805q 71605 71605q 71605e alarm connector specification p.108
• Adaptec raid 6805t 6805tq external alarm connector molex 22 28 4023 or equivalent alarm mating cable connector molex 50 57 9002 or equivalent j12 p.108
• Adaptec raid 6805t 6805tq activity led header connector molex 22 43 6030 or equivalent activity led header mating cable connector molex 22 55 2161 or equivalent j2 p.108
• Adaptec raid 7805 7805q 71605 71605q 71605e external alarm connector molex 22 28 4023 or equivalent alarm mating cable connector molex 50 57 9002 or equivalent j6 p.109
• Adaptec raid 71685 72405 78165 external alarm connector molex 22 28 4023 or equivalent alarm mating cable connector molex 50 57 9002 or equivalent j6 p.109
• Adaptec raid 71685 72405 78165 alarm connector specification p.109
