Hyundai H-CCR8088 (Без CD) [14/39] Operation
![Hyundai H-CCR8088 (Без CD) [14/39] Operation](/views2/1002636/page14/bge.png)
14
Operation
the panel or press REPEAT button on the RC
repeatedly for repeat playing in different modes:
track/chapter repeat, folder repeat, disc repeat,
repeat cancel (depending on the format used).
Random playback
Press RANDOM button on the RC or press
and hold DOWN/RDM/4 button on the panel to
activate random playing mode. Press one more
time to return to normal playing.
Goto
Press GOTO button to show the playback
parameters for the current chapter/track/
time (track/title/chapter number or time).
Press cursor buttons to navigate between the
parameters and use number buttons to input
needed settings. Press ENTER button on the
RC or ENTER/STOP/5 button on the panel to
start playback from the set number or time.
Picture setting
Press and hold SELECT button on the panel
or SEL button on the RC until the display shows
setting menu. Press LEFT/RIGHT cursor buttons
to select PIC menu page consisting of BRIGHT,
COLOR, CONTRAST and MODE items. Press
UP/DOWN cursor buttons to choose an item.
Press VOL+/VOL- buttons on the RC or rotate
VOLUME regulator on the panel to adjust the
selected item. After adjustment, leave the unit
idle for several seconds to save the setting.
Zooming in/out
During playback of video or images, press
repeatedly ZOOM button on the RC, the
picture will be zoomed in the sequence: X2 =>
X3 => X4 => X1/2 => X1/3 => X1/4 => Normal.
When the image is zoomed in, you can move it
by pressing cursor buttons.
Slow playback
During playback press repeatedly SLOW
button on the RC to select the speed of
slow playback: 1/2 => 1/4 => 1/8 => 1/16 =>
Normal. While slow playback, press
button
on the RC or PTY/
button on the panel or
press and hold SET/PAU/6 button on the panel
to resume normal playback.
OSD (On Screen Display) function
Press OSD button on the RC or press
and hold LEFT/OSD/1 button button on the
RC repeatedly to show current playback
information, such as number of track/chapter/
title, current track/chapter/title time elapsed/
remaining, total track/chapter/title time
remaining (depending on the file type).
Selecting audio language
During video playback repeatedly press
AUDIO button on the RC to select the audio
language (if any available).
Selecting video system
While video playback, press repeatedly
SYSTEM button on the RC or BND/NP button
on the panel to select the video system (NTSC/
PAL/AUTO).
Selecting subtitle language
If your video file supports multi-language
subtitle, press SUB-T button on the RC
repeatedly to switch among available languages.
Menu navigation
Press MEN/PBC button on the RC to
activate the root menu list on the screen.
Choose the desired item with cursor buttons.
Press ENTER button on the RC or ENTER/
STOP/5 button on the panel to confirm the
selected item and start playing.
ID3 Tag function
If an MP3 file has ID3-tag information in
the supported format, such information will be
displayed while playback.
