Quick reference
Bottom
Indicator Meaning
View Images button (34)
Wind Noise Reduct. (86)
Audio Level Display (88)
Low Lux (81)
EV AE Shift (81)
White Balance Shift (81)
Tele Macro (82)
Cinematone (82)
Shutter Speed (81)
IRIS (81)
White Balance (51)
Slide show button
101-0005
Data file name (37)
Protected image (60)
Histogram (47)
Audio Format (86)
9dB Gain (50)
Manual ring zoom (42)
Manual focus (81)
Indicators and their positions are approximate
and may differ from what you actually see.
