23
GB
Getting started
Step 4: Making setting adjustments before
recording
The LCD panel
Open the LCD panel 90 degrees to the camcorder (), and then adjust the angle ().
Tips
You can adjust the brightness of the LCD screen with [LCD Brightness ] (p.
94).
Changing the display on the LCD screen
Press the DISPLAY button to cycle the screen display in the following order: detailed display
simple display nondisplay.
Tips
In the default setting, the screen display changes to the simple display after about 4 seconds ([Display
Setting], p
. 94). The display changes to the detailed display when you touch anywhere on the screen
ex
cept the buttons on the LCD screen so that you can use items.
about 4sec
after
DISPLAY button
90 degrees (max.)
180 degrees (max.)
90 degrees to the camcorder
