21
GB
Getting started
4
Set [Summer Time], then touch [Next].
If you set [Summer Time] to [On], the clock advances 1 hour.
5
Select the date format, then touch [Next].
6
Select the date and time, touch
/ to set the value, then touch
[Next]
.
The clock starts.
Notes
The date and time does not appear during recording, but they are automatically recorded on the
recording media, and can be displayed during playback. To display the date and time, touch
(MENU) [Setup] [
(Playback Settings)] [Data Code] [Date/Time] .
If the button you touch does not react correctly, calibrate the touch panel (p. 119).
Once the clock is set, the clock time is automatically adjusted with [Auto Clock ADJ] (p
.
96) and [Auto
Area ADJ] (p.
97) set to [On]. The clock may not be adjusted to the correct time automatically, depending
on the country/region selected for your camcorder. In this case, set [Auto Clock ADJ] and [Auto Area
ADJ] to [Off].
Tips
Yo
u can embed date and time in the recording data (p. 84).
