Sony HXR-NX70P [54/132] Adjusting the recording level
![Sony HXR-NX70P [54/132] Adjusting the recording level](/views2/1028732/page54/bg36.png)
54
GB
Selecting the recording level
AUTO/MAN (CH1) switch
AUDIO LEVEL (CH1) dial
AUTO/MAN (CH2) switch
AUDIO LEVEL (CH2) dial
Switching wind noise reduction to
ON/OFF
LOW CUT (INPUT1) switch
LOW CUT (INPUT2) switch
Attach the XLR A
daptor (p. 12),
and connect the supplied
microphone to INPUT1 jack .
Set the INPUT1 (LINE/MIC/
MIC+48V) switch to MIC+48V.
Set the REC CH SELECT (INPUT1)
switch to CH1·CH2
This setting enables recording on both
CH1, CH2. Set the switch to CH1 if
you want to record on CH1 only.
Adjusting the recording level
You can adjust the recording level input
from the INPUT1 /INPUT2 jacks.
You cannot adjust the recording level of the
internal microphone and MIC input jack.
Set the AUTO/MAN (CH1/CH2)
switch of the channel to be
adjusted ( or ) to MAN.
Turn the AUDIO LEVEL dial or
to adjust the volume to the
proper level.
Confirm that the volume is at the
proper level with headphones or audio
lev
el meter (p. 88).
To restore automatic adjustment
Set the AUTO/MAN (CH1/CH2) switch
or to AUTO.
Reducing wind noise
You can reduce wind noise input from the
INPUT1/INPUT2 jacks or .
Set the LOW CUT (INPUT1) switch
or LOW CUT (INPUT2) switch to
ON.
Tips
You can select [
Audio Format] from
[Linear PCM] or [Dolby Digital] when
recording in high definition image quality
(HD).
You can adjust the volume of the headphones or
s
p
eaker with [Volume] (p. 86).
You can set [Audio Output Timing] of
h
e
adphones and audio output jacks (p. 86).
