Connection to
External equipment
11
EN
Connect the signal cable from the monitor output sock-
et of the PERSONAL COMPUTER to the RGB IN
socket of the set.
Connect the audio cable from the PC to the L/R IN
sockets of the set.
Press the INPUT SELECT button to select PC.
Switch on the PC, and the PC screen appears on the
set.
The set can be operated as the PC monitor.
RGB-DTV input signal : 480p-60Hz, 576p-50Hz,
720p-50Hz, 720p-60Hz, 1080i-50Hz, 1080i-60Hz.
Note: When the set is inputted RGB-DTV signal in
RGB-PC mode, automatically it is set to RGB-DTV
mode.
Connecting PC / DTV
RGB IN
L/R
IN
AV2V2
VIDEOVIDEO
AUDIOAUDIO
L
R
6
6
< Back panel of the set >
