Rolsen RL-15X11 [29/240] Connection of pc

Connection of PC

You can adjust horizontal/vertical position, clock, phase,

and auto-configure, reset as you prefer.

Press the MENU button and then D / E button to select

the SETUP menu.

Press the G button and then D / E button to select the

desired picture item.

Press the F / G button to make appropriate adjustments.

H-Position / V-Position

This function is to adjust picture to left/right and up/down

as you prefer.

Clock

This function is to minimize any vertical bars or stripes vis-

ible on the screen background. And the horizontal screen

size will also change.

Phase

This function allows you to remove any horizontal noise

and clear or sharpen the image of characters.

Auto-configure

This function is for the automatic adjustment of the screen

position, clock and phase. The displayed image will disap-

pear for a few seconds while the Auto-configuration is in

progress.

Reset

This function allows you to return to the good picture repro-

duction programmed at the factory and cannot be

changed.

Note : Some signal from some graphics boards may not

function properly. If the results are unsatisfactory, adjust

your monitor’s position, clock and phase manually.

Press the OK button to store it for the PC monitor picture.

Press the EXIT button to return to PC mode.

PC Setup

SETUP

()}{ OOOKOOMENUOOEXIT

Language

CSM

PC Control

VGA Mode

When the set is inputted 480p signal in VGA mode, select 480P on the SETUP menu.

VGA mode

SETUP

()}{ OOOKOOMENUOOEXIT

H-Pos. 5

V-Pos. 100

Clock 50

Phase 15

Auto

Reset

Language

CSM

PC Control

VGA Mode

PC Control

SETUP

()}{ OOOKOOMENUOO EXIT

640x480

480P

Language

CSM

PC Control

VGA Mode
