Rolsen RL-15X11 [28/240] Connection of pc

Connection of PC

1. Connect the signal cable from the monitor output sock-

et of the PERSONAL COMPUTER to the PC input

socket of the set.

2. Connect the audio cable from the PC to the PC

SOUND sockets of the set.

3. Press the INPUT SELECT button to select PC.

4. Switch on the PC, and the PC screen appears on the

set.

The set can be operated as the PC monitor.

Note : If you have an Apple macintosh, connect the VGA

desktop block (not supplied) from the 3 row 15 pin to 2 row

15 pin with the signal cable and connect the VGA desktop

block to the Macintosh.

Displayable Monitor Specification

(Synchronization input form : separate)

Note :

a. If the set is cold, there may be a small “flicker” when

the set is switched on. This is normal, there is nothing

wrong with the set.

b. If possible, use the VESA 1,024x768@60Hz video

mode to obtain the best image quality for your LCD

monitor. If used under the other resolutions, some

scaled or processed pictures may appear on the

screen. In this case, set the PC vertical frequency to

60Hz. The set has been pre-adjusted to the mode

VESA 1,024x768@60Hz.

c. Some dot defects may appear on the screen, like Red,

Green or Blue spots. However, this will have no impact

or effect on the monitor performance.

d. Do not press the LCD screen with your finger for a long

time as this may produce some temporary distortion

effects on the screen.

e. When the PC screen appears on the set, a message

may appear on the screen, and the message will differ

according to the Window system version (Win98,

2000). If a message appears click “Next” until the mes-

sage finishes.

f. If the message Out of Range” appears on the

screen, adjust the PC as in the ‘Displayable Monitor

Specification’ section.

PC in socket (D-Sub jack)

DOS

VESA(VGA)

VESA(SVGA)

VESA(XGA)

VESA(SXGA)

VESA(WXGA)

720x400

640x480

800x600

1024x768

1152x864

1280x768

37.9KHz

31.5KHz

37.9KHz

37.5KHz

35.1KHz

37.9KHz

48.1KHz

46.9KHz

48.4KHz

56.5KHz

60.0KHz

67.5KHz

47.7KHz

70Hz

60Hz

72Hz

75Hz

56Hz

60Hz

72Hz

75Hz

60Hz

70Hz

75Hz

60Hz

35.50MHz

25.17MHz

31.50MHz

36.00MHz

40.00MHz

50.00MHz

49.50MHz

65.00MHz

75.00MHz

78.75MHz

108.00MHz

80.136MHz

Proposed

Resolution H-freq(KHZ) V-freq(HZ) Pixel clock(MHZ)
