Connections of
Back panel
7
EN
1. S-VIDEO INPUT
connect video out from an S-VIDEO VCR to the S-
VIDEO input.
2. AERIAL SOCKET
3. AUDIO/VIDEO SOCKET
Connect the audio/video out sockets of the VCR to AV
sockets of the set.
4. RGB INPUT / L/R IN
Connect the set output socket of the PERSONAL COM-
PUTER to this socket.
5. EURO SCART SOCKET
connect the euro scart socket of the VCR to these sock-
ets.
6. POWER CORD SOCKET
This set operates on an AC power. The voltage is indi-
cated on the Specifications page. Never attempt to
operate the set on DC power.
()
