Sony SLV-E480EG [56/60] Rear panel

Additional Information

Rear panel

1 Mains lead (7)

2 AERIAL IN

ANTENNE ENTREE connector (7)

3 AERIAL OUT

ANTENNE SORTIE connector (7)

4: LINE-1 (TV)

: LIGNE-1 (TV) connector (7, 46)

5 NTSC PB (PlayBack) switch (25)

continued
