ELECTRICAL CONNECTION

• Connect the hood to the mains through a two-pole switch hav-

ing a contact gap of at least 3 mm.

• Remove the grease filters (see paragraph Maintenance) being

sure that the connector of the feeding cable is correctly inserted

in the socket placed on the side of the fan.

Chimney Assembly

• Fasten the Chimney fixing element 19 to the Body using 4

screws 12c.

Upper chimney

• Open the two side pieces out slightly, hook them up behind the

brackets 7.2.1 and bring them back together again until they

are in contact.

• Fix to the Brackets at the sides, using 4 screws 12c (2.9 x 9.5)

provided.

• If there are any, make sure that the Connector extensions outlet

is in correspondence with the Chimney openings.

Lower chimney

• Open the two side pieces of the Chimney out slightly, hook

them between the upper chimney and the wall, and then close

them together again until they are in contact.

• Fix the part at the sides to the Chimney fixing element 19, us-

ing 2 screws 12c (2.9 x 9.5) provided.
