Setup (Menu) Mode
FTM-3100R Operating Manual
Menu Item Function Available Values Default
40: TS SPEED
Selects the Tone Search or DCS Search
Scanner speed.
FAST/SLOW FAST
41: VER DISP
Displays the transceiver software version CPU x.xx ---
42: WX ALERT
Enables/Disables the Weather Alert fea-
ture.
ON/OFF OFF
43: WX VOL
Selects the audio output level of the
Weather Alert.
NOR VOL/MAX VOL NOR VOL
44: W/N DEV
Reduction of the Microphone Gain/Devia-
tion and receiver bandwidth.
WIDE/NARROW WIDE
ø: Depends on the transceiver version.
