118
Customizing Menu Settings and User Preferences
Setup-menu listing
Menu / Item Description
Selectable options
(Options in bold are the default
settings)
7 PRG REV TONE Set the idle line squelch 300 Hz to 3000 Hz 1500 Hz
8 BELL RINGER Sets the number of
successive bell rings
OFF / 1 time / 3 times / 5 times /
8 times / CONTINUOUS
9 SQL EXPANSION Sets the squelch
type separately for
transmission and
reception
ON / OFF
10 WX ALERT
(USA Version Only)
Weather alert operation
setting
ON / OFF
5 SCAN
1 DUAL WATCH STOP Sets the signal reception
method
AUTO / HOLD
2 SCAN DIRECTION Sets the scanning
direction when scanning
starts
UP / DOWN
3 SCAN RESUME Sets the operation when
scanning stops
BUSY / HOLD / 1 sec / 3 sec / 5 sec
4 DUAL WATCH MODE Sets the reception time
while processing the
dual reception function
0.3 sec to 10 sec 5.0 sec
6 GM
1 RANGE RINGER Activates/deactivates
the alert sound when
detecting stations within
communication range
OFF / ON
2 MESSAGE POPUP Activates/deactivates
the pop-up message
display
OFF / ON
3 RADIO ID Displays the transceiver
IDs
- (uneditable)
* For details of the functions, refer to the GM Function Instruction Manual.
7 WIRES-X
1 RPT/WIRES FREQ
FREQ
Sets the operating
frequencies for
repeater and WIRES-X
operations.
Registers the preset
frequency
MANUAL / PRESET
Depends on the transceiver version
* For details of the functions, refer to the WIRES-X Instruction Manual.
8 CONFIG
1 DATE & TIME ADJUST Sets the date and time
using the internal clock
month/day/year, hour : minute
2 TIME FORMAT Sets the time display
format
24 hour / 12 hour
3 TIME ZONE Sets the time zone UTC ±14h (0.5 h interval) UTC ±0:00
4 AUTO REPEATER
SHIFT
Activates/deactivates
the automatic repeater
shift function
OFF / ON
5 REPEATER SHIFT Sets the repeater shift
direction
SIMPLEX / − REPEATER / + REPEATER
(Differs depending on frequency)
6 REPEATER SHIFT
FREQ
Sets the repeater shift
width
0.000 to 99.950MHz
(Differs depending on frequency)
