17
Before Use
Nameandfunctionofeachcomponent
Rear
① ⑤ ②
④
③
➀ ANT terminal
Connect the antenna.
➁ 13.8V DC
Connect the provided DC power supply cable (with fuse attached).
➂ EXT SP jack
Connect the optional external speaker.
➃ DATA jack
Connect a cable for remote operation or a cable for connecting to devices such as
your computer interface unit and the external terminal unit.
➄ Cooling fan
