Yaesu FTM-100DR [2/176] Introduction

Before Use

Introduction

Features of this transceiver

 144/430 MHz dual-band transceiver equipped with standard C4FM digital

communication modulation

 Clear audio and data communication are achieved using the digital modulation

functions

 Wide-band receives in the 108 MHz to 999 MHz range (air band, information wireless

band)

 Transmit power 50 watts with cooling fan

 The dot matrix LCD is mounted on the front panel

 500 memory channels in the A-band and 500 channels in the B-band

 Your frequency memory channels and transceiver configuration settings can be backed

up using a micro-SD memory card. The data on the micro-SD memory card can easily

be copied to other transceivers

 A choice of scanning functions (including VFO scan, memory scan)

 Built-in GPS receiver unit displays your station location and movement information.

Connection to external GPS devices is enabled.

 Incorporated APRS

function enables data communication of location information and

messages

*Refer to the separate “APRS Instruction Manual”

 GM (Group Monitor) function in which frequently communicating members can be

registered as a group, thereby allowing location information and messages to be

exchanged

*Refer to the separate “GM Instruction Manual”

 Supports Yaesu WIRES-X Internet linking, enabling communication with remote

partners via the Internet

*Refer to the separate “WIRES-X Instruction Manual”

 Bluetooth adaptor unit BU-2 (sold separately) permits hands-free operation

 Voice guide unit FVS-2 (sold separately) provides voice announcements and recording

of received audio

* The WIRES-X, APRS, and GM Instruction Manuals are not included with this product.

Please download them directly from the Yaesu website.
