22
Installation and Connection
Installing the transceiver
Installation location when used in a mobile unit
● Front panel
To efficiently receive the GPS satellites, it is recommended that the transceiver should
be installed on the dashboard or front side of the center console. See “Installing the
front panel” on page 26
Tip The GPS reception antenna is built into the front panel.
Where the GPS antenna
is built in
● Main body
It is recommended that the main body be installed below the car dashboard or to either
side of the center console. See “Installing the main body” on page 25
Controller
Transceiver main body
