ASRock X399M Taichi [10/103] Specifications
![ASRock X399M Taichi [10/103] Specifications](/views2/1307882/page10/bga.png)
English
2
1.2 Specications
Platform
•
Micro ATX Form Factor
•
8 Layer PCB
•
2oz Copper PCB
CPU
•
Supports AMD TR4 Socket Ryzen readripper Series CPUs
•
IR Digital PWM
•
11 Power Phase design
Chipset
•
AMD X399
Memory
•
Quad Channel DDR4 Memory Technology
•
4 x DDR4 DIMM Slots
•
Supports DDR4 3600+(OC)/3200(OC)/2933(OC)/
2667/2400/2133 ECC & non-ECC, un-buered memory
(U-DIMM)*
* Please refer to Memory Support List on ASRock’s website for
more information. (http://www.asrock.com/)
•
Max. capacity of system memory: 64GB
•
15μ Gold Contact in DIMM Slots
Expansion
Slot
•
3 x PCI Express 3.0 x16 Slots (PCIE1/PCIE2/PCIE3: single at
x16 (PCIE1); dual at x16 (PCIE1) / x16 (PCIE2); triple at x16
(PCIE1) / x16 (PCIE2) / x16 (PCIE3))*
* Supports NVMe SSD as boot disks
•
Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
•
Supports NVIDIA® Quad SLI
TM
and SLI
TM
•
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ac module (on the rear I/O)
•
15μ Gold Contact in VGA PCIe Slot (PCIE1, PCIE2 and
PCIE3)
Audio
•
7.1 CH HD Audio with Content Protection (Realtek
ALC1220 Audio Codec)
•
Premium Blu-ray Audio support
•
Supports Surge Protection
