ASRock X399M Taichi [51/103] English
![ASRock X399M Taichi [51/103] English](/views2/1307882/page51/bg33.png)
English
43
X399M Taichi
M.2_SSD (NGFF) Module Support List
Vendor Interface Length P/N
ADATA PCIe3 x4 2280 ASX7000NP-128GT-C
ADATA PCIe3 x4 2280 ASX8000NP-256GM-C
ADATA PCIe3 x4 2280 ASX7000NP-256GT-C
ADATA PCIe3 x4 2280 ASX7000NP-512GT-C
ADATA PCIe3 x4 2280 ASX8000NP-512GM-C
Corsair PCIe3 x4 2280 CSSD-F240GBMP500
Intel PCIe3 x4 2280 SSDPEKKF256G7
Intel PCIe3 x4 2280 SSDPEKKF512G7
Kingston PCIe2 x4 2280 SH2280S3/480G
OCZ PCIe3 x4 2280 RVD400-M2280-512G (NVME)
Plextor PCIe3 x4 2280 PX-128M8PeG
Plextor PCIe3 x4 2280 PX-1TM8PeG
Plextor PCIe3 x4 2280 PX-256M8PeG
Plextor PCIe3 x4 2280 PX-512M8PeG
Plextor PCIe 2280 PX-G256M6e
Plextor PCIe 2280 PX-G512M6e
Samsung PCIe3 x4 2280 SM961 MZVPW128HEGM (NVM)
Samsung PCIe3 x4 2280 PM961 MZVLW128HEGR (NVME)
Samsung PCIe3 x4 2280 960 EVO (MZ-V6E250) (NVME)
Samsung PCIe3 x4 2280 960 EVO (MZ-V6E250BW) (NVME)
Samsung PCIe3 x4 2280 SM951 (NVME)
Samsung PCIe3 x4 2280 SM951 (MZHPV256HDGL)
Samsung PCIe3 x4 2280 SM951 (MZHPV512HDGL)
Samsung PCIe3 x4 2280 SM951 (NVME)
Samsung PCIe x4 2280 XP941-512G (MZHPU512HCGL)
SanDisk PCIe 2260 SD6PP4M-128G
SanDisk PCIe 2260 SD6PP4M-256G
TEAM PCIe3 x4 2280 TM8FP2240G0C101
TEAM PCIe3 x4 2280 TM8FP2480GC110
WD PCIe3 x4 2280 WDS256G1X0C-00ENX0 (NVME)
WD PCIe3 x4 2280 WDS512G1X0C-00ENX0 (NVME)
For the latest updates of M.2_SSD (NFGG) module support list, please visit our website for
details: http://www.asrock.com
