ASUS WS X299 SAGE
1-7
Chapter 1
1.1.5 Expansion slots
Unplugthepowercordbeforeaddingorremovingexpansioncards.Failuretodosomay
causeyouphysicalinjuryanddamagemotherboardcomponents.
Slot No. Slot Description
1 PCIE3.0/2.0x16_1slot
2 PCIE3.0/2.0x16_2slot(x0/x8mode)
3 PCIE3.0/2.0x16_3slot(x16/x8mode)
4 PCIE3.0/2.0x16_4slot(x0/x8mode)
5 PCIE3.0/2.0x16_5slot(x16/x8mode)
6 PCIE3.0/2.0x16_6slot(x0/x8mode)
7 PCIE3.0/2.0x16_7slot(x16/x8mode)
