Asus ROG MAXIMUS X HERO [56/110] Chapter 2
![Asus ROG MAXIMUS X HERO [56/110] Chapter 2](/views2/1307905/page56/bg38.png)
2-14
Chapter 2: Basic Installation
Chapter 2
* LAN ports LED indications
** Audio 2, 4, 6 or 8-channel configuration
SPEED
LED
ACT/LINK
LED
LAN port
Activity Link LED Speed LED
Status Description Status Description
OFF No link OFF 10Mbpsconnection
ORANGE Linked ORANGE 100Mbpsconnection
BLINKING Data activity GREEN 1 Gbps connection
Port
Headset
2-channel
4-channel 6-channel 8-channel
LightBlue LineIn LineIn LineIn
SideSpeakerOut
Lime Line Out FrontSpeakerOut FrontSpeakerOut FrontSpeakerOut
Pink MicIn MicIn MicIn MicIn
Orange – –
Center/Sub
woofer
Center/Sub
woofer
Black
– RearSpeakerOut RearSpeakerOut RearSpeakerOut
