1.1.7 Onboard LEDs
1. Q LEDs (BOOT, VGA, DRAM, CPU)
QLEDscheckkeycomponents(CPU,DRAM,VGAcard,andbootingdevices)in
sequenceduringmotherboardbootingprocess.Ifanerrorisfound,thecorresponding
LEDremainslituntiltheproblemissolved.Thisuser-friendlydesignprovidesan
intuitivewaytolocatetherootproblemwithinseconds.
2. CPU ready LED (CPU_READY)
ThisLEDwillindicatethecurrentstatusofyourCPU.AredlightindicatesthattheCPU
isnotreadytoboot,andtheLEDwillturngreenoncetheproblemissolved.Thisuser-
friendlydesignhelpsyouquicklyidentifywhetheryourCPUisreadytobootornot.
TheorderwhichtheLEDslightupmayvaryperCPU.
