Asus ROG CROSSHAIR VI HERO [53/100] Atx power connection
![Asus ROG CROSSHAIR VI HERO [53/100] Atx power connection](/views2/1307916/page53/bg35.png)
ASUS CROSSHAIR VI HERO
2-7
Chapter 2
2.1.5 ATX power connection
OR AND
• DO NOT connect the 4-pin power plug only, the motherboard may overheat under
heavy usage.
• Ensure to connect the 8-pin power plug, or connect both the 8-pin and 4-pin power
plugs.
