2-14
Chapter 2: Basic Installation
Chapter 2
• ThepluggedUSB3.0devicemayrunonxHCImodeorEHCImode,dependingonthe
operating system’s setting.
• USB3.0devicescanonlybeusedasdatastorageonly.
• WestronglyrecommendthatyouconnectUSB3.0devicestoUSB3.0portsforfaster
and better performance for your USB 3.0 devices.
* LAN ports LED indications
Dedicated Management LAN port (DM_LAN1) LED indications
Activity/Link LED Speed LED
Status Description Status Description
OFF Nolink OFF 10 Mbps connection
ORANGE Linked ORANGE 100 Mbps connection
BLINKING Data activity GREEN 1Gbpsconnection
ACT/LINK
LED
SPEED
LED
Activity/Link LED Speed LED
Status Description Status Description
OFF Nolink OFF 10 Mbps connection
GREEN Linked ORANGE 100 Mbps connection
BLINKING Data activity GREEN 1Gbpsconnection
SPEED
LED
SPEED
LED
ACT/LINK
LED
ACT/LINK
LED
** Audio 2, 4, 6, or 8-channel configuration
Port Headset
2-channel
4-channel 6-channel 8-channel
LightBlue LineIn LineIn LineIn LineIn
Lime LineOut FrontSpeakerOut FrontSpeakerOut FrontSpeakerOut
Pink Mic In Mic In Mic In Mic In
Orange – – Center/Subwoofer Center/Subwoofer
Black – RearSpeakerOut RearSpeakerOut RearSpeakerOut
Gray – – SideSpeakerOut* SideSpeakerOut
